4 Four Colour Flexo Printing Machine Stack Type High Speed
More video check here !
Sample Pictures:
Main Features:
1. Printing color group may change according to customer requirements, can print both sides of the completion of a one-time continuous.
2. The host can use frequency electromagnetic.
3. Electric Smart Thermostat.
4. Single drying tunnel design, easy to wear materials.
5. 1 color to 12 colors can be customized according to your need.
6. The printing machine all can choose advance configurations to achieve the high quality, the high-definition effect.
Details: customized is available
Printing Unit:
Drying Unit:
Unwind & Rewind Unit: double rewinder, tension controller with magnetic powder, web guide device, corona treatment is optional
Material After Printing Finished:
Main Technical Parameters:
| 1 | Printing color | 1 color to 4 colors |
| 2 | Type of printing | flexo printing stack type |
| 3 | Suitable material | roll plastic film BOPP / OPP / PE / HDPE / LDPE / PVC, roll paper, roll woven sack, roll non woven fabric, roll aluminum foil and so on |
| 4 | Material feeding width | 600mm / 800mm / 1000mm / 1200mm … (according to your material) |
| 5 | Max. material width | 600mm / 800mm / 1000mm / 1200mm … |
| 6 | Max. printing width | 560mm / 760mm / 960mm / 1160mm … |
| 7 | Printing length | from 300mm up to 1000mm (customized is available) |
| 8 | Maximum Machine speed | 90 m/min |
| 9 | Printing speed | 10~80 m/min (depends on the specific material, ink, plate design, etc.) |
| 10 | Plate thickness | 1.7mm / 2.28mm / 2.84mm / 3.94mm (customized is available) |
| 11 | Suitable Ink | Water based ink / Solvent based ink |
| 12 | Register adjustment method | by manual |
| 13 | Register precision | Longitude：±0.35mm
Transverse：±0.35mm |
| 14 | Max. Diameter of unwind | Φ600 mm (jumbo diameter customized is available) |
| 15 | Max. Diameter of rewind | Φ600 mm (jumbo diameter customized is available) |
| 16 | Rewind and Unwind web cylinder | core 3 inches |
| 17 | Heating method | electricity heating |
| 18 | Power Supply voltage | 3 phase 380V，50Hz (customized is available) |
Please note: mentor company is continuously seeking for development of products. For this reason, mentor reserves the right to supply the improved product without advance notice.
Optional (need extra cost):
Please consult the supplier for this
| tension controller with magnetic powder | web guide device |
| corona treatment | auto loading for unwind and rewind |
| double unwind | double rewind |
| doctor blade | ceramic anilox roller |
4 color flexo printing machine, four colour flexo printing machine, flexo printing machine, flexo printing machine manufacturers, flexo printing machine price, flexo printing machine china, label flexo printing machine, flexo label printing machine, flexo paper printing machine, paper flexo printing machine, wrapping paper printing machine, plastic bag printing machine, polythene bag printing machine, stack type flexo printing machine, stack flexo printing machine, high speed flexo printing machine,
Brand we work with:
Production Process:
plastic bag making machine, check here
film blowing machine, check here
sheet cutting machine, check here
Package and Delivery:
What Does the Customer Say:
FAQ:
Q: What’s the price of machines?
A: Pls provide following information:
1)The photo of printing sample.
2)What material to print for?
3)How many color does your product need?
4)How much of your material width?
5)How much the maximum diameter and weight of roll material?
